Product Type: Hybrid Inverter
PV Input
Max. PV Input Power: 6000W
Max. DC Input Voltage: 500Vdc
Max. Input Current: 20A
MPPT Voltage Range: 120V-430V
AC Input
Nominal Operating Voltage: 230Vac
Nominal Operating Frequency: 50/60Hz
Max. Input Current: 40A
AC Output
Rated Output Power: 5500VA/5500W
Nominal AC Output Voltage: 208/220/230/240Vac
Nominal AC Frequency: 50/60Hz
Surge Power(3 seconds): 8250VA
Nominal AC Output Current: 25A
Battery(parallel connection)
Rated Voltage: 51.2V
Rated Capacity: 280Ah
Rated Energy: 7168Wh
Voltage Range: 44.8-56V
Charge Voltage Range: 56-57.6V
Cut-off Voltage: 44.8V
Recommend Charge Current: 50A
Max Charge Current: 100A
Max Discharge Current: 150A
General
Temperature:-10℃~ +55℃
Protective Class: Class I
Ingress Protection: IP31
